80A Robot Lawn Mover

50A Robot Mower&Transpoter

The Smart Field All-in-One Mowing and Transport Robot innovatively integrates two core functions: intelligent mowing and automatic transport following, empowering a comprehensive upgrade of field operations. It easily conquers all terrains, including 30° steep slopes, overgrown fields, orchards, and terraced farms, while its 24/7 operation capability with autonomous charging significantly boosts efficiency. Operators can activate the "follow-me" mode with a lightweight handheld device, enabling the robot to follow the user on the go. This single machine meets both mowing and transport needs, reducing labor costs by up to 70% while ensuring precise and stable performance in complex environments.Redefining field productivity with high integration, intelligence, and versatility, it delivers efficient, safe, and cost-effective automated solutions for farms, photovoltaic parks, and hilly orchards!

Product Introduction
The Smart Field All-in-One Mowing and Transport Robot innovatively integrates two core functions: intelligent mowing and automatic transport following, empowering a comprehensive upgrade of field operations. It easily conquers all terrains, including 30° steep slopes, overgrown fields, orchards, and terraced farms, while its 24/7 operation capability with autonomous charging significantly boosts efficiency. Operators can activate the "follow-me" mode with a lightweight handheld device, enabling the robot to follow the user on the go. This single machine meets both mowing and transport needs, reducing labor costs by up to 70% while ensuring precise and stable performance in complex environments.Redefining field productivity with high integration, intelligence, and versatility, it delivers efficient, safe, and cost-effective automated solutions for farms, photovoltaic parks, and hilly orchards!
Features

Dual-mode operation:

remotecontrol and

 follow-me switching.

Multi-functional mowing

robot suitable for both

mowing and transport applications.

Equipped with brushless motors

for energy efficiency and durability;

high-standard generators ensure

low failure rates and long service life.

Simple and reliable remote

controlsystem with low failure rate.

Electric Drive System:

Compatiblewith lithium batteries or

 hybriddirect-drive range extenders.

Quick-Detach System design for

lightweight structure andeasy

 loading/unloading.

Single-hand remote control:

easier and more flexible operation.

Electric drive design support

sattachment expansion for

multiplefunctions in one machine.

Adjustable Cutting Height (5-15cm):

Remote-controlled bladeelevation

 for diverse terrains.

Reinforced Track System:

Internal steel frame with wire

mesh + externalengineering rubberfor

wear resistance.

Reinforced low-profile chassis

excelsat climbing slopes and

crossing ditches.

Customizable Performance:

Adjustable cutting height

andmowing speed via remote.

Wide Application: Ideal for wildgrass,

lawns, embankments,orchards, hills,

terraces, solar farms, and landscaping.

Labor-Saving Automation:

Replaces manual hauling/transport,

cutting labor costs by up to 70%.

Expandable Cargo Tray:

Telescopic design accommodates

 multiplecrate sizes and scenarios.

Parameter
Host Machine
Overall Dimensions
Machine Size 1070 × 920 × 860 mm (L × W × H)
Maximum Size (with cargo rack) 1330 × 1230 × 860 mm (L × W × H)
Structural Weight 108 kg (machine) + 25 kg (cargo rack)
Maximum Load Capacity 150 kg
Mowing Motor
Rated Power 4 kW
Operating Voltage 48V
Speed 0–6000 rpm (adjustable)
Drive Motor
Operating Voltage 48V
Travel Speed Up to 2.5 km/h
Remote Control Range 0–200 m
Working Slope Up to 30°
Power Supply
Type Lithium iron phosphate (LiFePO₄) battery
Travel Speed Up to 2.5 km/h
Remote Control Range 0–200 m
Working Slope Up to 30°
Cutting Blades
Blade Type 21-inch straight blade / 21-inch swing blade
Blade Speed 0–6000 rpm
Cutting Width 500 mm
Cutting Height 50–150 mm
Follow Distance
Adjustable Range 1–7 meters
  • Features
  • Specifications
  • Application
Features

Dual-mode operation:

remotecontrol and

 follow-me switching.

Multi-functional mowing

robot suitable for both

mowing and transport applications.

Equipped with brushless motors

for energy efficiency and durability;

high-standard generators ensure

low failure rates and long service life.

Simple and reliable remote

controlsystem with low failure rate.

Electric Drive System:

Compatiblewith lithium batteries or

 hybriddirect-drive range extenders.

Quick-Detach System design for

lightweight structure andeasy

 loading/unloading.

Single-hand remote control:

easier and more flexible operation.

Electric drive design support

sattachment expansion for

multiplefunctions in one machine.

Adjustable Cutting Height (5-15cm):

Remote-controlled bladeelevation

 for diverse terrains.

Reinforced Track System:

Internal steel frame with wire

mesh + externalengineering rubberfor

wear resistance.

Reinforced low-profile chassis

excelsat climbing slopes and

crossing ditches.

Customizable Performance:

Adjustable cutting height

andmowing speed via remote.

Wide Application: Ideal for wildgrass,

lawns, embankments,orchards, hills,

terraces, solar farms, and landscaping.

Labor-Saving Automation:

Replaces manual hauling/transport,

cutting labor costs by up to 70%.

Expandable Cargo Tray:

Telescopic design accommodates

 multiplecrate sizes and scenarios.

Parameter
Host Machine
Overall Dimensions
Machine Size 1070 × 920 × 860 mm (L × W × H)
Maximum Size (with cargo rack) 1330 × 1230 × 860 mm (L × W × H)
Structural Weight 108 kg (machine) + 25 kg (cargo rack)
Maximum Load Capacity 150 kg
Mowing Motor
Rated Power 4 kW
Operating Voltage 48V
Speed 0–6000 rpm (adjustable)
Drive Motor
Operating Voltage 48V
Travel Speed Up to 2.5 km/h
Remote Control Range 0–200 m
Working Slope Up to 30°
Power Supply
Type Lithium iron phosphate (LiFePO₄) battery
Travel Speed Up to 2.5 km/h
Remote Control Range 0–200 m
Working Slope Up to 30°
Cutting Blades
Blade Type 21-inch straight blade / 21-inch swing blade
Blade Speed 0–6000 rpm
Cutting Width 500 mm
Cutting Height 50–150 mm
Follow Distance
Adjustable Range 1–7 meters
